4MP Explosion-Proof Underwater IP Camera | 200m Depth | IP68 | Ex d IIC T6 Gb | POE

4MP Explosion-Proof Underwater IP Camera | 200m Depth | IP68 | Ex d IIC T6 Gb | POE

Part of YingDiGe’s Subsea & ROV Inspection Cameras series — professional underwater imaging systems engineered for ROV operations, offshore inspection, and hazardous area subsea monitoring.

4MP Explosion-Proof Underwater IP Camera — 200m Depth | IP68 | Ex d IIC T6 Gb Certified

The only explosion-proof model in the Subsea & ROV Inspection Cameras series, this 4MP camera carries Ex d IIC T6 Gb certification — the highest level of flameproof enclosure protection for gas group IIC environments. For offshore oil & gas platforms, petrochemical facilities, and hazardous area subsea monitoring where standard cameras are not permitted, it provides the compliance, 200m depth rating, and POE network connectivity required for safe, reliable operation in classified zones.

Core Advantages

  • Ex d IIC T6 Gb Explosion-Proof Certified – Flameproof enclosure for gas group IIC (hydrogen) hazardous area compliance; mandatory for offshore oil & gas applications
  • 200m Depth Rating – Rated for sustained subsea deployment in offshore and nearshore hazardous environments
  • 4MP Ultra-HD with 0.005 Lux Starlight – 1/3" progressive scan CMOS for clear imaging in low-light subsea conditions
  • 316L Marine Stainless Steel Housing – Seawater-grade corrosion resistance; anti-fog structure for sustained optical clarity
  • POE + ONVIF/GB28181/ISAPI – Single-cable power and data; compatible with existing VMS platforms

Technical Specifications

Parameter Value
Resolution 4MP ultra-HD
Image Sensor 1/3" progressive scan CMOS
Minimum Illumination 0.005 Lux (starlight)
Explosion-Proof Standard Ex d IIC T6 Gb
Waterproof Rating IP68 (fully sealed)
Depth Rating 200m
Housing Material 304 / 316L marine stainless steel
Compression H.265 / H.264
Protocol ONVIF / GB28181 / ISAPI
Power POE
Cable 5m / 10m / 20m waterproof cable
Operating Temperature -20°C to +70°C
HS Code 852580
Country of Origin China

ROV & Subsea Inspection Applications

  • Offshore oil & gas platform hazardous area subsea monitoring
  • Petrochemical facility underwater surveillance in classified zones
  • LNG terminal and refinery underwater inspection
  • Subsea pipeline monitoring in Ex-rated hazardous environments
  • Naval and defense hazardous environment underwater cameras

Customization Available

Cable length (5m/10m/20m), depth rating, and protocol configuration are customizable. OEM service available for Subsea & ROV Inspection Camera system integrators.

Compliance: Ex d IIC T6 Gb explosion-proof certified. Products comply with RoHS and REACH directives. CE documentation available upon request.

Product features

High reliability, deep-water pressure resistance, intelligent imaging, strong anti-corrosion capability

Materials and care

POM,stainless steel 316L, aluminium alloy;Brass Gold Plating,Polymer material PEEK,Bronze C36000, stainless steel 316L, titanium alloy TC4, hard anodized aluminum 7075, neoprene rubber, polyether type TPU

Customization options

Customization is available for all
